This is a thin c-api wrapper programmatically generated for the excellent C++ immediate mode gui Dear ImGui. All functions are programmatically wrapped except constructors, destructors and ImVector. (Unless someone find a use case for them) Generated files are: cimgui_auto.cpp, cimgui_auto.h for C compilation. Also for helping in bindings creation, definitions.lua with function definition information and structs_and_enums.lua. This library is intended as a intermediate layer to be able to use Dear ImGui from other languages that can interface with C (like D - see D-binding)

Notes:

currently this wrapper is based on version [1.65 of Dear ImGui]
overloaded function names try to be the most compatible with traditional cimgui names. So all naming is algorithmic except for those names that were in conflict with widely used cimgui names and were thus coded in a table (https://github.com/cimgui/cimgui/blob/master/generator/generator.lua#L41). Until the community finish with defining this table tag will be 1.62beta. Current overloaded function names can be found in (https://github.com/cimgui/cimgui/blob/master/generator/generated/overloads.txt)

compilation

clone
make using makefile on linux/macOS/mingw (Or use CMake to generate project)

auto binding generation

update imgui folder to the version you desire.
run generator/generator.bat (or make a .sh version and please PR) with gcc and LuaJIT or Lua5.1 on your PATH.
as a result some files are generated: cimgui_auto.cpp and cimgui_auto.h for compiling and some lua/json files with information about the binding: definitions.json with function info, structs_and_enums.json with struct and enum info, impl_definitions.json with functions from the implementations info.
build as shown in https://github.com/sonoro1234/LuaJIT-ImGui/tree/master_auto_implementations/build
generate binding as done in https://github.com/sonoro1234/LuaJIT-ImGui/blob/master_auto_implementations/lua/build.bat

usage

use whatever method is in ImGui c++ namespace in the original imgui.h by prepending ig
methods have the same parameter list and return values (where possible)
functions that belong to a struct have an extra first argument with a pointer to the struct.
where a function returns UDT (user defined type) by value some compilers complain so another function with the name function_name_nonUDT is generated accepting a pointer to the UDT type as the first argument. (or second argument if it is a struct function)
also is generated function_name_nonUDT2 which instead of returning the UDT type returns a simple version (without functions) called UDTType_Simple (ImVec2_Simple for ImVec2)

example bindings based on cimgui
